Compact range · FTX-Q SERIES
FTX-45Q
ENGINEERED FOR IMPACT.
The FORTEX FTX-45Q is part of the enclosed Q-series hydraulic breaker range. Explore the key technical parameters to assess compatibility with your carrier and application.
Q enclosed housingØ45 mm chiselMG 2
45
120 kgNominal weight
1.2–3 tCarrier class
45 mmChisel diameter
20–40 L/minOil flow
TECHNICAL PRODUCT DETAILS
FTX-45Q SPECIFICATIONS
| Operating weight | 120 kg |
| Chisel diameter | Ø45 mm |
| Excavator class | 1.2–3 t |
| Mounting group | 2 |
| Required oil flow | 20–40 L/min |
| Working pressure | 90–120 kg/cm² |
| Impact rate | 700–1,200 bpm |
| Hose diameter | 3/8 or 1/2 inch |
| Back head pressure | 14–16 kg/cm² |
| Valve position | Internal |
| Accumulator pressure | Not specified |
Weights are rounded nominal figures. Hydraulic and carrier compatibility must be confirmed for each excavator. No noise or vibration reduction values are claimed without independent test results. Product imagery is illustrative.
